Gazolin Are A Industry & Manufacturing Services Provider Institutions. Suitable For Factory, Manufacturing, Industry, Engineering, Construction And Any Related Industry Care Field.
25/1, Thanneer Pandal-II, Lakshmi Nagar,
Peelamedu, Coimbatore - 641 004
| Model | PPS 260 |
|---|---|
| Tunnel Size ( W x H ) mm | 250 x 150 |
| Voltage ( V / Hz ) | 220 / 50 |
| Power Consumption ( KW ) | 3.3 |
| Conveyor Loading ( kg ) | 5 |
| Heating Furnance ( L x W x H ) mm | 760 x 250 x 150 |
| External Dimensions ( L x W x H )mm | 800 x 450 x 520 |
| Speed ( m / min ) | 0 ~ 6 |
| Heating Time ( minutes ) | 5 |
| Cooling Time ( minutes ) | 15 |
| Net Weight ( Kg ) | 40 |
Height Adjustable
| Model | PP 3020 |
|---|---|
| Tunnel Size ( W x H ) mm | 300 X 200 |
| Voltage ( V / Hz ) | 220 / 50 |
| Power Consumption ( KW ) | 4.5 |
| Conveyor Loading ( kg ) | 10 |
| Heating Furnance ( L x W x H ) mm | 900 X 300 X 50 - 200* |
| External Dimensions ( L x W x H )mm | 1200 x 500 x 800 |
| Speed ( m / min ) | 0 ~ 10 |
| Heating Time ( minutes ) | 10 |
| Cooling Time ( minutes ) | 15 |
| Net Weight ( Kg ) | 70 |
Height Adjustable
| Model | PP 4525 |
|---|---|
| Tunnel Size ( W x H ) mm | 450 x 250 |
| Voltage ( V / Hz ) | 220 / 50 - 380 / 50 |
| Power Consumption ( KW ) | 6.5 |
| Conveyor Loading ( kg ) | 10 |
| Heating Furnance ( L x W x H ) mm | 900 X 450 X 50 - 200* |
| External Dimensions ( L x W x H )mm | 1200 x 650 x 1240 |
| Speed ( m / min ) | 0 ~ 10 |
| Heating Time ( minutes ) | 10 |
| Cooling Time ( minutes ) | 15 |
| Net Weight ( Kg ) | 90 |
Height Adjustable
| Model | PP 4535 |
|---|---|
| Tunnel Size ( W x H ) mm | 450 x 350 |
| Voltage ( V / Hz ) | 380 / 50 |
| Power Consumption ( KW ) | 9.6 |
| Conveyor Loading ( kg ) | 30 |
| Heating Furnance ( L x W x H ) mm | 1200 x 450 x 50 -350* |
| External Dimensions ( L x W x H )mm | 1200 x 650 x 1340 |
| Speed ( m / min ) | 0 ~ 10 |
| Heating Time ( minutes ) | 10 |
| Cooling Time ( minutes ) | 15 |
| Net Weight ( Kg ) | 120 |
Height Adjustable
| Model | PP 6535 |
|---|---|
| Tunnel Size ( W x H ) mm | 650 x 350 |
| Voltage ( V / Hz ) | 380 / 50 |
| Power Consumption ( KW ) | 12.5 |
| Conveyor Loading ( kg ) | 30 |
| Heating Furnance ( L x W x H ) mm | 1200 x 650 x 50 -350* |
| External Dimensions ( L x W x H )mm | 1200 x 850 x 1340 |
| Speed ( m / min ) | 0 ~ 10 |
| Heating Time ( minutes ) | 10 |
| Cooling Time ( minutes ) | 15 |
| Net Weight ( Kg ) | 150 |
Height Adjustable
| Model | PPSC 5540 |
|---|---|
| Voltage ( V / Hz ) | AC 220 / 50 |
| Power (KW ) | 4 |
| Packing Speed ( pcs / h ) | 700 ~ 1000 |
| Max Packing Dimensions (L x W x H ) (mm) | 500 x 375 x 250 |
| Dimensions ( L x W x H ) (mm) | 1945 x 795 x 1080 |
| Weight ( Kg ) | 80 |
| Model | PP 4535 LDPE |
|---|---|
| Conveyor Load | 15 kg |
| Motor | 90 W |
| Voltage | 380 V 50 / 60 Hz |
| Conveyor Type | Mesh |
| Shrink Oven Size | 1200 x 450 x 350 ( mm ) |
| Pauiy Size | 2300 x 780 x 1100 ( mm ) |
| Machine Size | 2200 x 700 x 1000 (mm) |
| Net Weight ( Kg ) | 200 kg |
| Model | PPS 1538 L |
|---|---|
| Voltage | 220 V / 50 - 60 Hz |
| Power | 8 KW |
| Tunnel Size ( L x W x H )mm | 1000 x 150 x 380 |
| Max. Packing Size (mm) | ¢ 105 x 350 H |
| Conveyor Motor | AC 90W / 220V |
| Conveyor Speed | 0 ~ 10m / min |
| Maximum Loading | 15KGS |
| Shrink Film | POF, PVC, PP |
| Dimension(mm) | 1500 x 350 x 1500 |
| Net Weight ( Kg ) | 96 KGS |
