| Model | PPCS 900 L MS |
|---|---|
| Voltage ( V / Hz ) | 220 / 50 |
| Power (W) | 650 |
| Sealing Speed (m/min.) | 0 - 12 |
| Sealing Width (mm) | 8 ~ 10 |
| Temperature range (Deg.C) | 0 ~ 300 |
| Distance from the sealing center to the conveying table (mm) | 10 ~ 40 |
| Conveyor size (L x W) mm | 840 x 153 |
| Film Thickness (mm) | 0.08 |
| Single Conveyor Loading (Kg) | 1 |
| Overall Conveyor Loading (Kg) | 3 |
| Overall Dimension (LxWxH)mm | 840 x 380 x 320 |
| Net Weight (Kg) | 28 |
| Model | PPCS 900 V MS |
|---|---|
| Voltage ( V / Hz ) | 220 / 50 |
| Power (W) | 650 |
| Sealing Speed (m/min.) | 0 - 12 |
| Sealing Width (mm) | 8 ~ 10 |
| Temperature range (Deg.C) | 0 ~ 300 |
| Distance from the sealing center to the conveying table (mm) | 150 ~ 270 |
| Conveyor size (L x W) mm | 840 x 153 |
| Film Thickness (mm) | 0.08 |
| Overall Conveyor Loading (Kg) | 3 |
| Overall Dimension (LxWxH)mm | 840 x 380 x 320 |
| Net Weight (Kg) | 31 |
| Model | PPCS 900 L SS |
|---|---|
| Voltage ( V / Hz ) | 220 / 50 |
| Power (W) | 650 |
| Sealing Speed (m/min.) | 0 - 12 ( 0-16 ) |
| Sealing Width (mm) | 8 ~ 10 |
| Temperature range (Deg.C) | 0 ~ 300 |
| Distance from the sealing center to the conveying table (mm) | 10 ~ 40 |
| Conveyor size (L x W) mm | 840 x 153 |
| Film Thickness (mm) | 0.08 |
| Single Conveyor Loading (Kg) | 1 |
| Overall Conveyor Loading (Kg) | 3 |
| Overall Dimension (LxWxH)mm | 840 x 380 x 550 |
| Net Weight (Kg) | 32 |
Nitrogen Flushing Band Sealer is also available
| Model | PPCS 900 V SS |
|---|---|
| Voltage ( V / Hz ) | 220 / 50 |
| Power (W) | 650 |
| Sealing Speed (m/min.) | 0 - 12 ( 0-16 ) |
| Sealing Width (mm) | 8 ~ 10 |
| Temperature range (Deg.C) | 0 ~ 300 |
| Distance from the sealing center to the conveying table (mm) | 150 ~ 270 |
| Conveyor size (L x W) mm | 840 x 153 |
| Film Thickness (mm) | 0.08 |
| Single Conveyor Loading (Kg) | 1 |
| Overall Conveyor Loading (Kg) | 3 |
| Overall Dimension (LxWxH)mm | 840 x 380 x 550 |
| Net Weight (Kg) | 37 |
Nitrogen Flushing Band Sealer is also available
| Model | PPCS 900 L W |
|---|---|
| Voltage ( V / Hz ) | 220 / 50 |
| Power (W) | 750 |
| Sealing Speed (m/min.) | 0 - 12 ( 0 - 16 ) |
| Sealing Width (mm) | 8 ~ 10 |
| Temperature range (Deg.C) | 0 ~ 300 |
| Conveyor size (L x W) mm | 840 x 300 |
| Film Thickness (mm) | 0.08 |
| Overall Conveyor Loading (Kg) | 5 kg |
| Distance from the sealing center to the conveying table (mm) | 500 mm |
| Net Weight (Kg) | 40 kg |
| Model | PPCS 900 V W |
|---|---|
| Voltage ( V / Hz ) | 220 / 50 |
| Power (W) | 750 |
| Sealing Speed (m/min.) | 0 - 12 ( 0 - 16 ) |
| Sealing Width (mm) | 8 ~ 10 |
| Temperature range (Deg.C) | 0 ~ 300 |
| Conveyor size (L x W) mm | 840 x 300 |
| Film Thickness (mm) | 0.08 |
| Overall Conveyor Loading (Kg) | 5 kg |
| Distance from the sealing center to the conveying table (mm) | 500 mm |
| Net Weight (Kg) | 50 kg |
| Model | PPCS 1100 |
|---|---|
| Voltage | 110V/220V 50-60Hz |
| Power | 1235W |
| Sealing Speed | 0-12 m/min |
| Sealing Width | 6-12mm |
| Temperature Range | 0-300 C° |
| Max. Conveyor Loading | 10 kgs |
| Printing Category | Steel Wheel Printing |
| Machine Size | 1243*580*1228mm |
| Net Weight | 42 kgs |
