| Model | PP 101 H |
|---|---|
| Max. Strap Size (mm) | Not Stipulated |
| Min. Strap Size (mm) | 60 x 30 |
| Strapping Speed ( seconds ) | 1.5 |
| Strap Width (mm) | 6 - 15 |
| Strap Force ( Newton ) | 450 |
| Working Table Height (mm) | 750 / 500 |
| Power Source ( V / Hz ) | 220 / 50, ¼ HP |
| External Dimension (mm) (LxWxH) | 900 x 580 x 750 / 500 |
| Weight (kg) | 90 |
| Model | PP 101 L |
|---|---|
| Max. Strap Size (mm) | Not Stipulated |
| Min. Strap Size (mm) | 60 x 30 |
| Strapping Speed ( seconds ) | 1.5 |
| Strap Width (mm) | 6 - 15 |
| Strap Force ( Newton ) | 450 |
| Working Table Height (mm) | 750 / 500 |
| Power Source ( V / Hz ) | 220 / 50, ¼ HP |
| External Dimension (mm) (LxWxH) | 900 x 580 x 750 / 500 |
| Weight (kg) | 90 |
| Model | PP 101 HR |
|---|---|
| Max. Strap Size (mm) | Not Stipulated |
| Min. Strap Size (mm) | 60 x 30 |
| Strapping Speed ( seconds ) | 1.5 |
| Strap Width (mm) | 9 / 12 / 15 |
| Strap Force ( Newton ) | 450 |
| Working Table Height (mm) | 750 |
| Power Source ( V / Hz ) | 220 / 50, ¼ HP |
| External Dimension (mm) (LxWxH) | L900 x D580 x H750 |
| Weight (kg) | 90 |
| Model | PP 101 LR |
|---|---|
| Max. Strap Size (mm) | Not Stipulated |
| Min. Strap Size (mm) | 60 x 30 |
| Strapping Speed ( seconds ) | 1.5 |
| Strap Width (mm) | 9 / 12 / 15 |
| Strap Force ( Newton ) | 450 |
| Working Table Height (mm) | 500 |
| Power Source ( V / Hz ) | 220 / 50, ¼ HP |
| External Dimension (mm) | L900 x D580 x H500 |
| Weight (kg) | 80 |
| Model | SP 740H ( Deluxe Model ) Heavy Duty |
|---|---|
| Cycle Time | 1.5 sec / strap |
| Tension Range | 15 - 45 kgs |
| Strap Width | 6 - 15 adjustable |
| Sealing Method | Heating element |
| Reel Inside Diameter | 200mm |
| Power Supply | 220 / 50 / 1PH |
| Table Height | 780mm |
| Power Consumption | 0.5 KW |
| Layout Dimension | L902 x D575 x H780 mm |
| Weight | 110 kgs |
| Model | PP 740 L |
|---|---|
| Cycle Time | 1.5 sec / strap |
| Tension Range | 15-45 kgs |
| Sealing method | Heating Element |
| Strap Width (mm) | 9 / 12 / 15 |
| Reel Inside Diameter | 200mm |
| Table Height | 500mm |
| Power Supply | 220 / 50/1HP |
| Power Consumption | 0.5 KW |
| Layout Dimension | L902*D575*H510 |
| Weight (kg) | 100 |
