| Model | PP MRBL |
|---|---|
| Labeling Speed | ≤ 30 pcs/ min. (according to size) |
| Labeling Accuracy | ±0.5 mm |
| Min. Label Roll inner Diameter | ≥75 mm |
| Max. Label Roll out Diameter | ≤ Ø 150 mm |
| Bottle Diameter | 15- 150 mm |
| Label Size (mm) | 10- 100 mm (W) 10-300 mm (L) |
| Dimension | 380 x 380 x 440 (mm) |
| Weight | 19 kg |
| Model | PP RBL D |
|---|---|
| Efficiency | ≤ 50pcs/ min (according to overall size of the label) |
| Precision | ± 1 mm |
| Applicable bottles of diameter | Ø 10- 130 mm |
| Label size | Width 8- 150mm Length 15 - 210 mm |
| Label roll | External diameter 300mm Inner diameter: 75mm |
| Power supply | 220 V, 50 Hz 120 W |
| Machine size (mm) | 650 (L) * 450 (W) * 450 (H) mm |
| Machine weight (Kg) | 20 Kg |
| Model | PP RBL R |
|---|---|
| Efficiency | ≤ 50pcs/ min (according to overall size of the label) |
| Precision | ± 1 mm |
| Applicable bottles of diameter | Ø 10- 130 mm |
| Label size | Width 8- 150mm Length 15 - 210 mm |
| Label roll | External diameter 300mm Inner diameter: 75mm |
| Power supply | 220 V, 50 Hz 120 W |
| Machine size (mm) | 650 (L) * 450 (W) * 450 (H) mm |
| Machine weight (Kg) | 19 Kg |
